DVB-T/T2 Compact Monitoring Probe
EdgeProbe Nano DVB-T/T2

There are no reviews yet.

EdgeProbe Nano is the most tiny and compact RF probe with no compromise on Quality!

SKU: EdgeProbe Nano DVB-T/T2 Category:

EdgeProbe Nano DVB-T/T2 - Ask for Quote

Please fill in the following information and detail your monitoring needs. Also indicate if possible the software options you would be interested in.

Applications

  • Network operators
    • automate the tests of new transmitter
    • temporary monitoring/investigation tool
    • rebroadcasting receiver: RF to ASI or IP
  • Broadcasters: off-air monitoring probe to validate the on-air content
  • TV/STB producers: automated tests against a professional receiver
  • Labs: easy & simple access to live DTV sources via RF

Benefits

  • Small, Silent & Magnetized: can be installed anywhere
  • Remotely accessible, compatible with low bandwidth control networks (GPRS/3G)
  • Portable tool for maintenance team
  • Easy to use and configure
  • Standalone: no need for PC
  • Enables SNMP test automation
  • Low power consumption 8W

With its small, compact and easy to handle design, the EdgeProbe Nano DVB-T/T2 is the ideal tool for field technicians to transport in order to validate and monitor 24/7 all points of a DTV network.
EdgeProbe Nano is able to monitor DVB-T and DVB-T2 signals through its RF input (144 x 137 mm compact format).
Combined with a Network Monitoring System or not, the EdgeProbe Nano provides a powerful broadcast network alert & diagnosis tool allowing DTV network operators to monitor global trends and anticipate potential failures.

Monitor DVB-T & DVB-T2 signals

Signal Level, MER, SNR, BER

Modulation parameters, L1 signaling in DVB-T2, TPS in DVB-T

Channel Impulse Response

DVB-T, DVB-T2 (1.1.1, 1.2.1, 1.3.1) & T2 Lite support

Scanning mode for sequential monitoring of multiple RF channels

Complete MPEG-2 TS Monitoring

ETSI TR 101 290 Priority 1, 2, 3

QoS indicators (optional): Service Availability Error & Service Degradation Error

Verify Regionalization: Service Plan view, PID/Service presence, Scrambling

Service & components bitrates

Powerful Rebroadcasting Receiver - Gateway from RF to ASI/IP

Forward the analyzed TS over ASI output

Forward the analyzed TS over IP control port (VLAN support)

32 GB of internal storage

Alarm logs up to 6 months

RF parameter trends up to 6 months

TS recording (manual trigger)

Remote connection

Compatible with all Network Monitoring Systems, providing a powerful network alert & diagnosis tool: monitor global trends and anticipate potential failures.

Compatible SNMP v2c and v2c INFORM for alarming and device configuration

Web GUI access: support of low bandwidth Internet connection (3G, GPRS)

INTERFACES

  • RF
  • *

  • Connector In
  • 1 x RF input (F-type female – 75 Ω)

  • Standard
  • DVB-T, DVB-T2 (including 1.3.1), DVB-T2 Lite

  • Frequency range
  • 40 to 1000 MHz

  • Sensitivity
  • -80 to -5 dBm

  • Channel bandwidth
  • 1.7, 5, 6, 7 & 8 MHz

  • Control/Data
  • 1x Gigabit Ethernet for Web GUI, SNMP-V2C and IP Data in/out (VLAN support)

  • MPEG-2 TS
  • 1x ASI output (BNC-type female – 75 Ω)

MONITORING FEATURES

  • RF Monitor
  • *

  • Demodulation status
  • Lock / Unlock

  • Signal level
  • -90 to -5 dBm ±1 dBm, typically ±0.5 dBm, resolution 0.2 dBm

  • MER
  • 0 to 40 dB (0 to 36 dB: ±1 dB, 36 to 40 dB: ±2 dB)

  • SNR
  • 0 to 40 dB ±1 dB

  • BER (DVB-T)
  • Pre/Post-Viterbi, Post-RS

  • BER (DVB-T2)
  • Pre/Post-LDPC, Post-BCH

  • Modulation parameters
  • L1 signaling in DVB-T2, TPS in DVB-T

  • Channel Impulse Response (CIR)
  • *

  • TS Monitor Base
  • MPEG-2 TS Monitor, ETSI TR 101 290 Priority 1 and 2

  • TS Monitor Advanced
  • ETSI TR 101 290 Priority 3, QoS (SAE/SDE)

  • Service Plan
  • Verify regional services, Service & PID bitrates, Scrambling, Service & PID presence

  • Scanning
  • Monitor sequentially multiple channel frequencies over 1 RF input

  • Extended Memory
  • 32 GB of internal storage for: Event logs up to 6 months, Trends up to 6 months, TS recording

  • TRANSBOX
  • Coupled with a TRANSBOX device, EdgeProbe can provide service transcoding and forward to third-party analysis systems: service extraction from the input TS (SPTS or MPTS), real-time audio/video transcoding: 1 to 10 Mbps output bitrate, transcoded SPTS forward over IP Data

PHYSICAL

  • Height: 30 mm / 1.2 in, Width: 144 mm / 5.6 in, Depth: 137 mm / 5.3 in
  • Power supply: 12 VDC, 100-240 VAC to 12 VDC adapter provided
  • Power consumption: 8W

ENVIRONMENT

  • Operating temperature
  • -20 to 55°C / -4 to 131°F

  • Storage temperature
  • -20 to 70°C / -4 to 158°F

  • Humidity
  • 0 to 95%, non condensing

EdgeProbe Nano DVB-T/T2 includes by default:

  • Hardware: 1x (RF in, ASI out) & 1x IP Control in compact 144 x 137 mm format
  • Software:
    • DVB-T/T2 RF monitor: RF parameters, Channel Impulse Response
    • TS forward over ASI or IP outputs
    • VLAN support for IP forward

Software Options

  • Scanning: Multiple RF channels sequential monitoring
  • TS Base Monitor: ETR290 Priority 1, 2
  • TS Advanced Monitor: ETR290 Priority 3
  • Qos Monitor: SAE (Service Availability Error), SDE (Service Degradation Error)
  • Service Plan: Multiplex Service/PID monitoring
  • Extended Memory: 32 GB storage (trends, logs, TS record)

Hardware Options

  • TRANSBOX: Stream 1 or 2 compressed service(s)



Default Warranty

  • Standard: 1 YEAR Hardware Warranty and Basic Helpdesk (HW RMA)

Optional Support Services

  • Advance HW + SW 1/3/5 YEAR including:
    • Advance Replacement: hardware warranty with replacement before reception of faulty unit
    • Software Upgrade: access to all software updates & upgrades
    • Priority HelpDesk: priority access to the support helpdesk for any question on product usage, problem request, and change/improvement requests
  • Premium HW 1/3/5 YEAR including:
    • Premium Advance Replacement : hardware warranty with 1 business day replacement before reception of faulty unit (from a dedicated customer spare stock)
  • Premium SW 1/3/5 YEAR including:
    • Premium Software Support: SLA contract manager + guaranteed response time + 2 days per year local proactive visit (training including presentation of new available features, 1 TX site & or HE visit & configuration improvement, discussion on needs for new functionalities)
    • Software Upgrade: access to all software updates & upgrades
    • Priority HelpDesk: priority access to the support helpdesk for any question on product usage, problem request, and change/improvement requests

More details on the Waranties page.
