Video QoS & QoE Monitoring for Uncompressed Streams
StreamProbe 2110
StreamProbe solution provides a centralized overview of the Service Availability and Video Quality throughout all the strategic stages of the media processing & delivery flow, by 24/7 monitoring.
Ideal for all TV Service Providers & Network Operators – linear Broadcast TV, IPTV, Cable TV, Satellite TV, OTT, VOD, nPVR – Transport Contribution & Distribution and Service Platform Providers, looking to ensure the best End-User Quality of Experience all while optimizing OPEX.
"*" indicates required fields
Applications
- End-to-end Availability (QoS) and Quality (QoE) for all Video Services
- Increase uptime by detecting issues before your customers do
By 24/7 real-time supervision & alerting - Optimize daily operation & maintenance
Drill down analysis, on-error proof recording - Quality Reports generation for SLA commitments
- Compliancy 24/7 recording
Benefits
- One single unified web GUI for all Services Management
Contribution, encoding, packaging, transport, linear, VOD
Fast training of operational teams - All Services Quality view at-a-glance: Live Thumbnail Mosaic Wall
- Pay as you grow with flexible licensing & deployment architecture
HighDensity full SW solution – up to 100Gbps of uncompressed streams per 1RU Appliance
Ideal for content providers, media service providers : reliable 24/7 monitoring of the Service Availability and Quality.
StreamProbe offers a user friendly web GUI with a Live Thumbnail Mosaic view – at-a-glance overall view of the entire Service Quality for real-time supervision – and service dedicated technical views for drill down root cause analysis.
The monitoring information can be exported to generate Service Availability statistics and fault history reports. Real-time notifications can be sent out to 3rd party NMS systems or by email.
The solution is scalable with a flexible architecture wich can be tailored to different deployment scenarios: all-in-one, distributed, on prem bare metal or virtualized environements.
QoS - Service Availability & Integrity
- Uncompressed streams over IP: SMPTE ST 2110, ST 2022-6 (SDI over IP)
- IP transport issues detection (RTP, FEC)
QoE - Service Audio/Video Quality
- Full content monitoring
- Audio & Video defect detection: freeze, black screen, silence
- Video thumbnails display
- SD, HD, 3G, UHD support
Live Thumbnail Mosaic Wall
- All services view at-a-glance on a thumbnail wall, real-time update
- Highly customisable per user: grouping, audio levels, penalty box
- Monitoring by exception: display only faulty services – penalty box
System Integration & NBI
- Configurable alarming thresholds: general, daily and weekly alarm profiles configurable per service
- NMS integration: SNMPv2 support for alarm traps
- Monitoring information available via an open API (HTTP/JSON API)
- Service provisioning API for 3rd party NMS Orchestration
MONITORING FEATURES
- QoS - Service Availability & Integrity check
-
ST2110-20, ST2110-30 PCM, ST2022-6 video
FEC support (packets recovered/lost), IP jitter
- QoE - Service Audio/Video Quality
-
Video defect detection: freeze, black screen
Audio defect detection: silence, level too low/high, noise
Video pixel format: YCbCr-4:2:2; bits depth: 8 bits, 10 bits, Interlaced/Progressive
Audio sample rate: 44100, 48000, 96000; number of channels up to 64; sample depth: 16 bits, 24 bits
SD, HD, 3G, UHD
- Thumbnail Mosaic view
-
All services view at-a-glance on a thumbnail wall, real-time update
Highly customisable per user: grouping, audio levels, penalty box
Monitoring by exception: display only faulty services – penalty box
- System Integration & NBI
-
Configurable alarming thresholds: general, daily and weekly alarm profiles configurable per service
Alarm log history CSV export
SNMPv2 support for alarm traps
Monitoring information available via an open API (HTTP/JSON API)
Service thumbnails can be retrieved via API call – for 3rd party dashboard display
Service provisioning API for 3rd party NMS Orchestration
TECHNICAL CHARACTERISTICS
- SW solution: custom Linux OS
- Performance CPU, RAM, HDD depending on the bitrate capacity to monitor
- 100Gbps maximum capacity per Appliance
- Supporte input(s): 25Gb IP ports
StreamProbe 2110 – Perpetual Software License
- Bitrate capacity to monitor: Gbps
- SW pack
